XL23MB-W XLR Male IP65 Cable Connector 3-pin

Code: 8389

XL23MB-W XLR Cable Connector Male 3-pin IP65 black metal housing and orange boot solder cups

Price: €6.20
Price: €6.20
including 19% VAT Excluding VAT (For shipments to Non EU countries, or intra community upon VIES Validation) price, to be calculated during checkout
Get it within 24 hours, at your closest courier!
With free delivery for orders total € 100 +
Add to Cart

In Stock

years

XL23MB-W

XLR cable connector 3-pin. Plug-in IP65 protection with the appropriate XL23FB-W cable socket or the XL13FB-W panel socket. A handy shape and a well-formed and robust button make for a better user experience.
The rear nozzle is liquid and dustproof.

    • Length: 67.5 mm
    • Width: 19.5 mm
    • Height: 19.5 mm
  • Series: XLIP-Serie
  • Version: Cable version (plug/chassis)
  • Connector type: XLR male, 3-pin
  • Number of contacts: 3
  • Contact diameter: Ø 2.70 mm (x3)
  • Gender: Male plug
  • Housing color: Black
  • Connector housing material: ZZNAL4-1
  • Contact material: H59-1
  • Insulation material: High-performance plastics
  • Waterproof component: NBR
  • Cable diameter range: Ø 5.5–6 mm
  • Wiring mode: Solder contact
  • IP rating: IP65 (EN60529)
  • ROHS compliance: Yes (EN62321-1)
  • Operating voltage: < 50 V AC RMS
  • Insulation resistance: > 10 GΩ
  • Contact resistance: ≤ 3 mΩ
  • Plug cycles (durability): 1000
  • Operating temperature: down to -30°C
  • Country of origin: China
  • Applications: DJ, keyboard players, lighting technicians, singers, sound engineers
  • Markets: Event production, LED lighting (indoor/outdoor), industry, medical technology, mechanical engineering, device & plant construction, multimedia installations, digital signage, cable assembly, lighting, LED displays, broadcast, recording studios
