HD Production Systems
Pro Tools HD MADI 2

Avid Audio

Pro Tools HD MADI

Code: 6711

Pro Tools HD MADI

Price: €6598.00
Price: €6598.00
including 19% VAT Excluding VAT (For shipments to Non EU countries, or intra community upon VIES Validation) price, to be calculated during checkout
Add to Cart

Pre-Order

Enquire to be notified upon availability

years

Expand your Pro Tools|HD workflow to integrate with MADI-equipped devices—including routers and digital mixing consoles—with the all-digital HD MADI interface. The perfect solution for integrating Pro Tools|HD into post-production and broadcast environments, Avid HD MADI gives you great connection flexibility, fuss-free use through built-in sample rate conversion, and the ability to send and receive up to 64 channels of audio between your Pro Tools setup and MADI devices up to 2 km (1.24 miles) away—all with a single rack unit interface.

    • Send and receive up to 64 audio streams between Pro Tools|HD and other MADI devices
    • Maintain maximum audio fidelity, with up to 24 bit, 192 kHz sample rate support
    • Gain connection and routing flexibility through optical and coaxial connections:
    • 2 MADI inputs (optical and coaxial)
    • 2 MADI outputs (simultaneous optical and coaxial)
    • Forget having to match sample rates, thanks to built-in SRC on all I/O channels
    • Completely integrates with Pro Tools|HD for full input, output, and routing control
    • Sync to an external clock through dedicated BNC Word Clock and XLR AES/EBU connections when using SRC on output
    • Keep things in sync with versatile Clock support, including Internal, Loop Sync, Word Clock, AES/EBU, and MADI
    • Gain better device compatibility with 64-channel (non-Varispeed) and 56-channel (Varispeed) support (at 48 kHz)
    • Integrate Pro Tools|HD with MADI-equipped VENUE live sound systems for recording and Virtual Soundcheck
    • Verify and troubleshoot signals through status indicators and global I/O signal LEDs
    • Compact 1U rack-mountable design overcomes space limitations
    • Connects to Pro Tools|HD through two DigiLink Mini connections (32 audio channels each; cables and adaptors included)
