PDM-T1204 Stage Mixer 12-CHANNEL DSP-MP3

Code: 7642

PDM-T1204

Price: €468.00
Price: €468.00
BUY Online: €448.00
BUY Online: €448.00
You Save €20
You Save €20
including 19% VAT Excluding VAT (For shipments to Non EU countries, or intra community upon VIES Validation) price, to be calculated during checkout
Add to Cart

Pre-Order

Enquire to be notified upon availability

years

The PDM-T series is a series of stage mixers equipped with a 32-bit DSP effect processor, stereo 7-band graphic equalizer, BT streaming capability and USB input/output for easy connection to the computer for music recording, etc. It’s also possible to use the one click recording function for easy MP3 recordings on a USB stick. Each channel has its own gain control with treble, mid and bass controls. The microphone preamps offer selectable 48V phantom power on all microphone channels. The PDM-T mixers are designed to provide multi-channel mixing capabilities for bands, musicians, sound engineers, conferences, studio recording and a variety of other live stage applications.

    • 12-Channel multipurpose audio mixer
    • MP3 recording/playing via full-duplex USB port (one click recording)
    • BT receiver for audio streaming
    • +48V phantom power
    • Stereo 7-band graphic equalizer
    • 380 DSP multi effects with 4 memories
    • USB to PC for record and play music (USB interface)
    • 12x Microphone-/line input (Combi XLR/Jack)
    • High, Mid and Low control for each channel
    • Adjustable Pan, aux return input and FX send output
    • Adjustable headphone output
    • Stereo balanced main outputs (XLR/6.3mm Jack)
    • MUTE, PFL (Pre-fader listening), L/R, G1/G2 control on each channel
    • LED VU meter and Peak LEDs
  • Brand   : Power Dynamics
  • Product colour  :  Black
  • Playback options  :  BT streaming, USB
  • Input connections   : 6.3mm Jack, RCA, USB, XLR (3-pin)
  • Output connections   : 6.3mm Jack, RCA, USB, XLR (3-pin)
  • Presets   : 380
  • DSP Resolution   ; 32-bit
  • Frequency response   : 20Hz - 20.000Hz
  • THD   : <0,5%
  • Equalizer   ; 7-Bands
  • Equalizer: Low :  80Hz +15dB
  • Equalizer: High  :  12KHz +15dB
  • Power supply  :  100-240VAC 50/60Hz
  • Dimensions (L x W x H)  :  377 x 580 x 120 mm
  • Weight (kg)   : 5.95
