Tascam

DR-40XP

Code: 8295

4-Channel 32-Bit Float Portable Field Recorder With USB-C Interface and Adjustable Mics

Price: €268.00
Price: €268.00
BUY Online: €256.00
BUY Online: €256.00
You Save €12
You Save €12
including 19% VAT Excluding VAT (For shipments to Non EU countries, or intra community upon VIES Validation) price, to be calculated during checkout
Get it with Free Delivery within 24 hours, at your closest Akis Express Collection point!
Add to Cart

In Stock

years

The DR-40XP is designed for capturing professional quality recordings for music, audio-for-video, meetings, dictation, and more. It features 32-bit float recording with up to 96kHz sample rate for low-noise, distortion-free audio, and supports microSDXC cards up to 512GB. Two adjustable unidirectional stereo condenser microphones switch between A/B and X/Y configurations, complemented by two XLR/TRS inputs for 4-channel simultaneous recording. TASCAM's HDDA mic preamps deliver an EIN of −126dBu. A USB-C port enables use as a 2-in/2-out audio interface with Windows, Mac, and iOS. Additional features include a built-in chromatic tuner, reverb effect, low-cut filters, Auto Tone output for video sync, tripod mount, and up to 18 hours of battery life using the built-in microphones.

    • 4-ch recording : field recording, musicians and videographers
    • 32-bit float/24-bit/16-bit, 96kHz/48kHz/44.1kHz
    • A-B or X-Y unidirectional condenser microphones, up to 125dB SPL
    • Ultra-low noise mic preamps (HDDA / EIN -126dBu)
    • XLR/TRS mic/line inputs with +48V phantom power
    • 2-in/2-out USB-C audio interface
    • Approx. 18 hours battery operation (2-ch built-in mic/alkaline)
    • microSDXC (up to 512GB) cards can be used as recording media
    • USB Type-C port
    • Power options include three AA batteries, USB mobile battery, or optional AC adapter (PS-P520U)
    • Support multiple menu languages (ENG / FRA / DEU / ITA / ESP / RUS / PRT / JPN / CHI / KOR)
    • Long recordings as MP3 files possible
    • Various recording functions (Auto rec, Self timer, Pre rec)
    • Overdubbing function
    • Limiter and Peak reduction
    • Four low-cut filter levels (40 / 80 / 120 / 220Hz)
    • Input delay function [0-150 msec]
    • Auto Tone output for use with DSLR camera
    • Supports MS microphone recording
    • Reverb effect for vocal and instrument resonance
    • Mark function
    • Track increment and file divide function
    • Various playback control（Playback speed、In-out loop, Jump back）
    • 128×64 pixel graphic LCD with backlight
    • Tripod mounting point attaches to any standard tripod
    • Stereo mini line output and headphone output
    • Speed change (VSA) function for adjusting the speed from 0.5 to 2.0 times (in 0.1 increments)
    • Playlist function
    • Built-in monaural speaker makes it easy to check your recordings
    • Chromatic tuner for tuning musical instruments before recording
  • Recording Media & Formats:
  • Recording media: microSD, microSDHC, microSDXC (up to 512 GB)
  • WAV sampling frequency: 44.1 kHz / 48 kHz / 96 kHz
  • WAV bit depth: 16-bit / 24-bit / 32-bit float
  • MP3 sampling frequency: 44.1 / 48 kHz
  • MP3 bit rate: 32 / 64 / 96 / 128 / 192 / 256 / 320 kbps
  • Channels:
  • Maximum input channels: 4 (2 stereo)
  • Maximum recordable tracks: 4
  • EXT MIC/LINE IN (XLR-3-31, MIC or MIC+PHANTOM mode):
  • Input impedance: 2.4 kΩ or more
  • Minimum input level: −82 dBu
  • Maximum input level: +7 dBu
  • Phantom power: +24V or +48V (XLR only)
  • EXT MIC/LINE IN (LINE mode):
  • Input impedance: 10 kΩ or higher
  • Nominal input level: +4 dBu
  • Maximum input level: +24 dBu
  • PHONES/LINE OUT:
  • Connector: 3.5mm (1/8") stereo mini jack
  • Output impedance: 2.2 Ω
  • Nominal output level: −20 dBV (10 kΩ load)
  • Maximum output level: +0 dBV (10 kΩ load)
  • Maximum output: 20 mW + 20 mW (32 Ω load)
  • Recommended headphone impedance: 16–600 Ω
  • Built-in speaker: 0.3 W (monaural)
  • USB:
  • Connector: Type-C
  • Format: USB 2.0 High Speed Mass Storage / USB 1.1 Full Speed Audio Class
  • USB Audio sampling rate: 44.1 / 48 kHz
  • USB Audio bit depth: 24-bit
  • USB Audio inputs: 2 channels
  • USB Audio outputs: 2 channels
  • General:
  • Power: 3 AA batteries (alkaline/NiMH/lithium-ion) / 5V 0.5A USB bus power / PS-P520U AC adapter (DC 5V/2A)
  • Power consumption: 1.7 W (maximum)
  • Current consumption: 0.34 A (maximum)
  • Weight: 282 g (with batteries) / 213 g (without batteries)
  • Operating temperature: 0–40°C
  • Dimensions (mic closed): 70 × 155 × 35 mm (W × H × D)
  • Dimensions (mic open): 90 × 155 × 35 mm (W × H × D)
  • Audio Performance:
  • Frequency response: 20 Hz–20 kHz +0/−1 dB (44.1 kHz) / 20 Hz–22 kHz +0/−1 dB (48 kHz) / 20 Hz–40 kHz +0/−1 dB (96 kHz)
  • THD+N: 0.008% or lower
  • Dynamic range: 112 dB or higher
  • EIN: −126 dBu or lower
